Multi-GPU Inference Strategies for Large Language Models: Tensor Parallelism 101

Running a 70-billion-parameter language model on a single GPU? Impossible. Not because the model is too smart, but because it’s too big. Even the most powerful consumer GPUs today max out at 24GB or 80GB of memory. A model like Llama-2-70B needs over 140GB just to load its weights in half-precision. That’s where tensor parallelism comes in - the only practical way to split a massive model across multiple GPUs and still get fast, usable inference.

What Exactly Is Tensor Parallelism?

Tensor parallelism breaks down individual layers of a neural network and spreads their pieces across multiple GPUs. Think of it like cutting a cake into slices - each GPU gets a slice of every layer, not the whole layer. When the model runs, each GPU computes its slice, then quickly shares results with the others before moving to the next step.

This isn’t about running the same model on many GPUs (that’s data parallelism). It’s about splitting the model itself so that no single GPU has to hold everything. The technique was first formalized in NVIDIA’s Megatron-LM paper back in 2019, and today it’s the backbone of every major LLM inference system - from Hugging Face’s Text Generation Inference to NVIDIA’s TensorRT-LLM and vLLM.

The magic happens in the weight matrices. For example, in attention layers, the query, key, and value projections (q_proj, k_proj, v_proj) use column parallelism: each GPU gets a portion of the output columns, and inputs are copied to all devices. The output projection (out_proj) uses row parallelism: inputs are split across GPUs, and outputs are summed together. These two patterns are baked into every transformer layer, and frameworks handle the communication automatically.

Why It’s the Only Way to Run Big Models Today

Without tensor parallelism, you simply can’t run models larger than what fits on one GPU. Even if you had a 120GB GPU (which doesn’t exist for consumers), the cost and power draw would be insane. Tensor parallelism lets you run a 70B model on four 80GB A100s - or even on four 24GB RTX 4090s, as hobbyists have proven on Reddit.

NVIDIA’s benchmarks show that tensor parallelism reduces the memory footprint per GPU by the exact number of devices you use. Four GPUs? You need only a quarter of the memory per device. That’s why financial firms and healthcare providers - who need to run massive models for risk analysis or medical diagnostics - rely on it. According to Gartner, 75% of enterprise LLM deployments will use tensor parallelism by 2025. Right now, it’s already in 45% of them.

It’s not just about memory. It’s about speed. A 13B model on four GPUs using tensor parallelism runs 3.2 times faster than on one. That’s not linear scaling - but it’s enough to make real-time chat, document summarization, or code generation feel instant.

How It Compares to Other Parallelism Methods

There are three main ways to spread LLMs across GPUs: data, pipeline, and tensor parallelism. Each has trade-offs.

• Data parallelism copies the whole model to every GPU and runs different batches. Great for increasing throughput, useless if your model won’t fit on one GPU.
• Pipeline parallelism splits the model by layers - like giving GPU 1 the first 10 layers, GPU 2 the next 10, and so on. Simple to set up, but creates "pipeline bubbles" where some GPUs sit idle waiting for data. Studies show this wastes 30-60% of compute time.
• Tensor parallelism splits each layer. No idle GPUs. No bubbles. But every step requires heavy communication between devices.

For inference, tensor parallelism wins because latency matters more than batch size. You want a fast reply, not a big batch of replies. That’s why it dominates single-node deployments. Pipeline parallelism is better for training across multiple machines, but it’s too slow for real-time apps.

Hardware Requirements: It’s Not Just About GPU Count

You can’t just plug four consumer GPUs into a desktop and expect tensor parallelism to work well. The bottleneck isn’t the GPU - it’s the connection between them.

NVIDIA’s NVLink provides 600 GB/s bidirectional bandwidth between GPUs. PCIe 4.0? Only 32 GB/s. That’s a 20x difference. In real-world tests, using PCIe instead of NVLink adds 15-25% overhead to inference time. That means your 3.2x speedup drops to maybe 2.1x. For production, you need NVLink or equivalent high-speed interconnects.

Even then, communication adds latency. AWS Neuron SDK notes that each synchronization point (where GPUs exchange data) adds 1.2-2.5ms over EFA networking. NVIDIA’s NeuronLink cuts that to 0.3ms. That’s why cloud providers charge a premium for instances with NVLink - it’s not a luxury, it’s a requirement.

Practical Setup: How to Actually Use It

Getting tensor parallelism running is easier than it sounds - if you use the right tools.

• Hugging Face Text Generation Inference (TGI): Use --tensor-parallel-size 4 when starting the server. It auto-detects your GPUs and splits the model. No code needed.
• vLLM: Same flag. Set tensor_parallel_size to match your GPU count. Works with Llama, Mistral, Phi, and more.
• TensorRT-LLM: NVIDIA’s optimized engine. Supports FP8 quantization to cut communication volume by half. Requires more setup but gives the best performance.

Key rules:

• Match tensor parallel size to your GPU count. Don’t use TP=2 on 4 GPUs - it wastes resources.
• Use FP16 or BF16 precision. Avoid FP32 - it doubles memory and bandwidth use.
• Combine with quantization (like INT4) if you’re tight on memory. A 70B model in INT4 can fit on 2x 24GB GPUs with TP=2.

Most users get it working in under an hour using TGI or vLLM. The hard part isn’t the setup - it’s debugging.

Common Problems and How to Fix Them

Even with good tools, things break. Here’s what goes wrong - and how to fix it.

• Communication timeouts: If you see "allreduce timeout" errors (common in vLLM with TP>4), increase NCCL timeout settings. Set NCCL_ASYNC_ERROR_HANDLING=1 and NCCL_BLOCKING_WAIT=1.
• Incorrect results: Rare, but happens if tensor splits aren’t aligned. Always use frameworks that handle splitting automatically - don’t try to manually partition layers.
• Deadlocks: 32% of GitHub issues in vLLM are deadlocks. Usually caused by mismatched GPU topologies. Use nvidia-smi topo -m to check NVLink connections. Place processes so GPUs talking to each other are physically linked.
• Scaling beyond 8 GPUs: Communication overhead grows fast. Most models hit diminishing returns after 8 GPUs. If you need more, switch to pipeline + tensor hybrid parallelism.

The community is loud about this. Reddit users rave about running Llama-2-70B on 4x RTX 4090s. But developers complain that scaling beyond 8 GPUs is "not worth it." That’s not a flaw - it’s physics. More GPUs mean more communication. At some point, the wires become the bottleneck.

The Future: Hybrid Parallelism Is Coming

Tensor parallelism isn’t perfect. It’s the best tool we have for single-node inference, but it’s not the endgame.

NVIDIA’s TensorRT-LLM 0.5 (released May 2024) now compresses intermediate activations using FP8, cutting communication by 50%. That’s a big win. But the real shift is toward hybrid systems.

Stanford’s Center for Research on Foundation Models predicts that pure tensor parallelism will evolve into context-aware hybrids - where the system automatically switches between tensor, pipeline, and even expert parallelism based on the request. For example: a short prompt uses tensor parallelism for speed. A long document gets split into chunks and processed with pipeline parallelism across multiple nodes.

Mixture-of-Experts (MoE) models like Mixtral 8x7B are already pushing this forward. Instead of splitting every weight, expert parallelism assigns entire experts to different GPUs. That cuts cross-GPU traffic by 40-60%. Tensor parallelism still handles the dense layers, but the experts are distributed differently.

This is where the industry is headed. Not more GPUs in one box - smarter ways to use them across boxes.

Who Should Use Tensor Parallelism?

If you’re asking this question, here’s your answer:

• Use it if: You need to run models larger than 13B parameters, you have multiple GPUs with NVLink (or equivalent), and you care about low latency.
• Don’t use it if: You’re running models under 7B, you only have one GPU, or you’re using consumer-grade PCIe systems without high-speed interconnects.

For startups and researchers, vLLM and Hugging Face TGI make it free and easy. For enterprises, TensorRT-LLM offers enterprise support, SLAs, and optimization for production.

The bottom line: If you want to deploy a large language model today, tensor parallelism isn’t optional. It’s mandatory. The models are too big. The hardware is too limited. And this is the only method that lets you bridge the gap without sacrificing speed.

What’s Next?

If you’ve got a 13B+ model you’re trying to deploy, start with Hugging Face TGI. Set --tensor-parallel-size to your GPU count. Use FP16. Add quantization if memory is tight. Monitor latency and memory usage. If it works - you’ve just unlocked a model that would’ve been impossible to run a year ago.

The next step? Learn how hybrid parallelism works. Once you’ve mastered tensor parallelism, pipeline and expert parallelism become the natural next layer. But for now - focus on getting one model running well across multiple GPUs. That’s the real win.
